    Two Way NC Normally Closed Middle Pressure Solenoid Valve 1/2 Inch

    Ask Lasest Price
    Brand Name : ROUND STAR
    Model Number : BD
    Certification : ISO CE ROHS
    Price : USD
    Payment Terms : T/T, Western Union
    Supply Ability : ask for advice
    Delivery Time : 3~14 working days
    • Product Details
    • Company Profile

    Two Way NC Normally Closed Middle Pressure Solenoid Valve 1/2 Inch

    BD series 2-way piston ( NC ) middle pressure solenoid valve 1/4" ~ 1/2"


    working medium:water,liquid,air,light oil(viscosity≤20cst)

    medium temperature:-5 ~ 80℃

    working pressure: 0~60bar working type: (NC) DN1.5~2.5 direct acting DN6~12 pilot operated

    valvebody material:brass SS304, DN≥6 only brass sealing material:direct acting:VITON pilot operated:PTFE

    interface:G thread NPT thread

    Working voltage:AC220~240V AC110V 50/60Hz DC24V/12V direct acting AC28VA DC18W pilot operated AC18VA DC14W

    options:

    Rc thread LED light connector



    BD-series(NC)solenoid valve specification table

    model

    orifice size

    ( mm )

    interface sizeCvworking pressure(bar)

    A×B×C

    ( mm )

    Normal order codeWeight (Kg)
    AC200VDC24V

    AC220V

    G thread

    BD-015-081.51/4"0.060~400~4041×36×81BD-015-08 -AC220V0.43
    BD-020-082.00.120~300~3041×36×81BD-020-08 -AC220V0.43
    BD-025-082.50.20~250~2541×36×81BD-025-08 -AC220V0.43
    BD24000661/4"0.81~601~5048×30×102BD240006 - AC220V0.76
    BD24000883/8"1.11~601~5048×30×102BD240008 - AC220V1.15
    BD240012121/2"2.21~601~5060×35×117BD240012 - AC220V1.15
