    Normally Open NO High Pressure Gas Solenoid Valve , 3/8"Electromagnetic Solenoid Valve

    Ask Lasest Price
    Brand Name : ROUND STAR
    Model Number : YSE
    Certification : ISO CE ROHS
    Price : USD
    Payment Terms : T/T, Western Union
    Supply Ability : ask for advice
    Delivery Time : 3~14 working days
    • Product Details
    • Company Profile

    Normally Open NO High Pressure Gas Solenoid Valve , 3/8"Electromagnetic Solenoid Valve

    YSE series 2-way Stainless Steel ( NO ) high pressure solenoid valve 1/4" ~ 1"


    The main technical parameters


    ◆ Body material: stainless steel.

    ◆ Applicable medium: water, gas, oil, steam, gas, corrosive fluids.

    ◆ Temperature Range: -100- + 200 ℃.

    ◆ medium viscosity: less than 50C St (greater than to be customized).

    ◆ protection performance: waterproof, explosion-proof (Exd IICT5), anti-corrosion.

    ◆ Wiring: Terminal Block Type; lead type; male.

    ◆ Control mode: Normally open, normally closed.

    ◆ Power supply voltage: DC12-127V; AC36-380V.

    ◆ Connection: thread, flange (male and special interfaces or add custom adapter).

    ◆ Leakage amount: zero.



    YSE-series(NO)high pressure solenoid valve specification table


    model

    orifice

    ( mm )

    interface

    Cvworking pressure(bar)dimensionNormal order code

    weight

    (Kg)


    AC200VDC24V

    length×width×height

    A×B×C

    ( mm )

    AC220V

    G thread


    YSE-1K1

    1/4"

    or

    3/8"


    0.040~1500~15044×25×104YSE-1K - AC220V0.75
    YSE-1.5K1.50.080~650~6544×25×104YSE-1.5K - AC220V0.75
    YSE-2K20.150~350~3544×25×104YSE-2K - AC220V0.75
    YSE-2.5K2.50.200~200~2044×25×104YSE-2.5K - AC220V0.75
    YSE-3K30.250~150~1544×25×104YSE-3K - AC220V0.75
    YSE-10K10

    3/8"


    3.56~656~6560×55×131YSE-10K - AC220V1.30
    YSE-15K15

    1/2"


    4.76~656~6570×65×143YSE-15K - AC220V1.65
    YSE-20K20

    3/4"


    7.06~656~6580×74×148YSE-20K - AC220V2.15
    YSE-25K25

    1"


    116~656~6590×87×158YSE-25K - AC220V2.75
